Electric Siriusmed Ventilator , R30P Medical Portable Ventilator

Good integration:

Built-in active expiratory PEEP valve
Built-in O2 & Air mixture device
Built-in synchronized nebulizer
Built-in battery (≥ 90 mins)
Optional etCO2 , SPO2 monitoring module
Lung mechanics parameters and loops
Inspiratory hold with static compliance measurements
Manual inspiration
100% O2 suction
Nurse Call
72 hours Trend

Friendly interface

10.4”TFT touch screen, with a rotary knob.

Keyboard lock

Active Exhalation Valve

Achieves breathing during both inspiratory and expiratory.
Actively controls the target pressure, prevent airway pressure high
Promotes patient ventilator synchrony.
Modular exhalation valve & flow sensor is easily removable and serializable.

Features

Pneumatically driven and electronically controlled ICU ventilator
Usage range: Suitable for Adults,pediatrics and neonatal
Sufficient modes of Ventilation: VCV, PCV, SIMV-VC+PSV, SIMV-PC+PSV, SPONT/CPAP+PSV, BACKUP, Manual
Optional:PRVC,SIMV-PRVC, NIV-PC,NIV-CPAP, DuoPhasic+PSV ,APRV+PSV
Knob and Hard key input,Easy and fast selectable functions which enables single step functionality.
Easy to position ergonomic trolley with two brakes
Quick self-test no need frequent interaction from operator
Patient settings automatic stored and can be restored quickly
Direct setting of ventilation parameters in the main interface
3 waveforms and 2 loops on one interface, quick changeover able
System log keeps record of all types of alarms

Ventilator R30P- Knob And Hard Key Input,Easy And Fast Selectable Functions Which Enables Single Step Functionality.

System Speciﬁcations

Pneumatic Ventilator
10.4”,TFT display, with touch screen VCV, PCV, SIMV-VC, SIMV-PC, CPAP/PSV, (Optional APRV,PRVC, NIV ) BACKUP:见上描述 P-T, F-T, V-T(Optional: CO2-time, pulse rate-time) loop: P-V, F-V,P-F NI-MH battery, ≥90mins RS232, VGA, USB, Remote alarm
Operating Conditions
Gas supply: Air, O2, 280kPa -600kPa (41~87 PSI) Power supply: 100-240V, 50/60Hz Temperature: 10-40℃ (Operation), -20-60℃ (Storage) Relative humidity: 5%-95%, non-condensing (Operation) 5%-95% (Storage) Atmospheric pressure (Operation & Storage): 500hPa-1060hPa Dimensions (H×W×D): Ventilator: 455mm x 400mm x 300mm Trolley: 565mm X 535mmX 910mm Weight: Ventilator: 12.5 kg Trolley: 20 kg
Standards
IEC 60601-1, IEC 60601-1-2, IEC 60601-1-8, ISO 80601-2-12
Alarm		Upper limit		Lower limit
Tidal volume Minute volume Oxygen concentration Airway pressure Respiratory frequency ETCO2 Pulse rate Continuous pressure high Apnea alarm O2 SUPPLY DOWN alarm Mains failure alarm Battery power low alarm Battery discharged alarm Alarm silence		20~3000 mL 1~99 L 22~100%, OFF 1~99 cmH2O 1~120 bpm 0.1~13.3 kPa 31~250 bpm (PEEP+15) cmH2O, 15s 10~60s < 280 kPa Automatically switch < 10 min < 5 min ≤120 s		OFF,20~2999 mL 0~98 L 20~99% 0~98 cmH2O OFF,1~99 bpm 0~13.2 kPa 30~249 bpm (PEEP+15) cmH2O, 15s 10~60s < 280 kPa Automatically switch < 10 min < 5 min ≤120 s
Setting	Parameter		Monitoring		Parameter
Tidal volume (20ml) Respiratory frequency Inspiratory time Breath-hold time Pressure triggering Flowrate triggering PEEP Pressure support Pressure control High pressure level Low pressure level Oxygen concentration 100% O2 Thigh (optional) Freeze Expiratory hold Inspiratory hold Manual inspiration	20~2500mL 1~120 bpm 0.1~12 s 0~50% -20cmH2O~PEEP 0 [1] 0.5~20 L/min 0~50 cmH2O 0~80 cmH2O 5~80 cmH2O 5~80 cmH2O 0~50 cmH2O 21~100% 2min 0.1~30s Yes Yes Yes Yes		Inspiratory tidal volume Expiratory tidal volume Minute volume Spontaneous minute volume Spontaneous respiration frequency PEEP Airway peak pressure Mean airway pressure Inspiratory platform pressure Minimum airway pressure Inhaled oxygen concentration Airway resistance Compliance RSBI PEEPi Pulse Rate (Optional) EtCO2 (Optional)		0~4000 mL 0~4000 mL 0~99 L 0~99 L 0~120 bpm 0~120 bpm 0~100 cmH2O 0~100 cmH2O 0~100 cmH2O 0~100 cmH2O -20~100 cmH2O 15% ~100 % 0~600 cmH2O/(L/S) 0 ~ 300ml/cmH2O 0~9999bpm/L 0~100cmH2O 30~250 bpm 0 ~ 100 mmHg
